1600MM Tissue Paper Pulp Molding Machine

Name: 1600MM Tissue Paper Pulp Molding Machine
Brand: HUATAO
Price: 1 USD

Quality 1600MM Tissue Paper Pulp Molding Machine for sale

Brand Name : HUATAO

Model Number : HT027

Certification : CE

Place of Origin : CHINA

MOQ : 1pc

Payment Terms : L/C,T/T,Western Union,MoneyGram

Supply Ability : 20sets/moth

Delivery Time : 15days

Packaging Details : exported package

Processing Type : Pulp Molding Machine

Voltage : 220V/380V

Dimension(L*W*H) : 2300mm*1950mm*1600mm

Power(W) : 28kw~50kw

Weight : 2.5ton

Warranty : 1 YEAR, 12 months

Capacity : 1800-2000pcs/hour

Frequency : 50Hz-60Hz

packaging : standard export package

Contact Now

1600MM Tissue Paper Pulp Molding Machine

Product Specifications

Processing Type	Pulp Molding Machine
Voltage	220V/380V
Dimension (LWH)	2300mm1950mm1600mm
Power	28kw~50kw
Weight	2.5ton
Warranty	1 YEAR, 12 months
Capacity	1800-2000pcs/hour
Frequency	50Hz-60Hz

Product Description

1600MM Width Tissue Paper Pulp Molding Machine

Machine Description

This pulp molding machine uses waste paper as raw material to produce various products including egg trays, cartons, boxes, fruit trays, industrial trays, and seedling trays. The complete system includes pulp making, forming, and drying components.

Technical Specifications

Model	Capacity	Mould/pc	Weight (KG)	Dimension (LWH)	Motor (KW)	Workers
QS1*3	1000-1400	3	650	2300×2150×1850	2.2	3-4
QS1*4	1500-1800	4	700	2550×2150×1850	3	3-4
QS3*4	1800-2000	12	1350	2850×1750×1600	Speed adjustable-3	4-5
QS4*4	2000-2500	16	1500	3200170016000	Speed adjustable-3	4-5
QS4*8-1	3000-3500	32	2100	2600×2250×2300	Speed adjustable-3	3-4
QS4*8-2	4000-5000	32	2200	3000X2200x2300	Speed adjustable-3	5-6

Key Advantages

1-year warranty covering maintenance and repairs (excluding quick-wear parts)
Custom manufacturing service available - provide samples, photos, or dimensions
On-site installation support with 30 days of engineer assistance for setup, testing, and training

System Components

Pulping System: Waste paper is pulped in the pulper, with crushed pulp entering the pulp pool through hydraulic and friction action.

Forming System: Uses negative pressure and vacuum adsorption to convert pulp into products. Different molds create various tray types.

Drying System: Wet products are dried on a conveyor belt through a metal oven (180-250°C).

Packing System: Finished products are automatically stacked and packed for transport.

Product Images

1600MM Tissue Paper Pulp Molding Machine
